DJI Neo Drone
– Takeoff weight: around 135 grams
– Dimensions: 130x157x48.5 millimeters
– Maximum flight time: approximately 18 minutes
– Maximum flight distance: up to 7 kilometers
– Maximum wind resistance speed: 8 meters per second
– Operating temperature range: -10°C to 40°C
– Internal storage: 22GB
– Flight rating: CO
Flight Performance:
– Maximum ascent speed: 0.5 meters per second (cinematic mode), 2 meters per second (normal mode), 3 meters per second (sport mode)
– Maximum descent speed: 0.5 meters per second (cinematic mode), 2 meters per second (normal and sport modes)
– Maximum horizontal speed: 6 meters per second (normal mode), 8 meters per second (sport mode), 16 meters per second (manual mode)
– Maximum takeoff altitude: at an elevation of 2000 meters, vertical ascent of 120 meters in sport mode
Camera and Imaging:
– Image sensor: 1/2 inch
– Lens: 117.6° field of view, equivalent focal length 14mm, aperture f/2.8, focus distance from 0.6 meters to infinity
– ISO range: 100-6400
– Maximum image size: 12MP (4000 × 3000 4:3, 4000 × 2256 16:9)
– Video resolution: up to 4K 30fps with Electronic Image Stabilization (EIS) enabled
– Maximum video bitrate: 75Mbps
– Shutter speed: for video 1/8000-1/30 seconds, for photos 1/8000-1/10 seconds
– Still photography modes: single shot/timed shooting
– Photo format: JPEG
– Video format: MP4
– File system: exFAT
Transmission and Connectivity:
– Transmission system: DJI 04
– Live view quality: up to 1080p/30fps using the DJIRC-N3 remote controller
– Operating frequency: 2.4GHz, 5.1GHz, and 5.8GHz bands
– Maximum transmission distance: varies by region, up to 10 kilometers (FCC standard)
– Communication bandwidth: maximum 40MHz
– Transmission power (Equivalent Isotropically Radiated Power EIRP):
– 2.
4GHz: –
– 5.1GHz: –
– 5.8GHz: –
– Transmission range under interference:
– Strong (urban environment): 1.5-3 kilometers
– Moderate (suburban): 3-6 kilometers
– Low (suburban/seaside): 6-10 kilometers
Global Navigation Systems:
– Supports multiple satellite systems: GLONASS, GPS, Galileo, BeiDou
